Application

Aluminium coated with PVDF fluorocarbon coating has high weather resistance. It is made of roller coating with a unique double or triple coating process.

The chemical name of PVDF is polyvinylidene fluoride, which has a special chemical structure. The carbon-fluorine (CF) bond energy in the molecular structure is very strong (485KJ/MOL).  Only a small percentage of the ultraviolet light in sunlight can break the CF bond.Therefore, sunlight has almost no effect on it.The coated aluminum coil  is highly weather-resistant under wind and sun, and its surface is not easily got discoloration, it has acid and alkali corrosion resistance and excellent gloss retention.

Aluminum-magnesium-manganese alloy color-coated aluminum sheet contains a certain proportion of metal magnesium and manganese to increase the strength and processing performance of the aluminum alloy. Usually It is well coated with good weather resistance,PVDF coating Aluminum-magnesium-manganese color-coated aluminum sheets are mainly used in metal roof and wall systems.

Aluminum honeycomb panels are a series of metal composite panel products developed in combination with aviation industry composite honeycomb panel technology. The product adopts a "honeycomb sandwich" structure, with the surface and bottom made of high-strength aluminum alloy color-coated coils, and the middle is an aluminum honeycomb core composited by a special process.

FEVE 4F fluorocarbon coated aluminum sheet ismade of FEVE fluorocarbon coating with high weather resistance, combined with a unique double coating process roller coating. This product belongs to the fluorocarbon category. The high-energy carbon-fluorine bond in the molecular structure of the coating makes the product extremely weather-resistant. It has the same advantages and completeness as PVDF fluorocarbon coated aluminum sheets in terms of weather resistance. The FEVE 4F fluorocarbon coating has four carbon-fluorine bonds, so it has higher stability.

Carbon resin, whether inorganic pigments or organic pigments can be well soluble in FEVE resin, and can be used to adjust the color to very bright colors.

The product has better color selectivity and glossiness that PVDF cannot match. The coating hardness, acid and alkali resistance are also better than PVDF coating.

Our high-performance polyester HDPE coated aluminum sheet should actually be called high-weather-resistant polyester HDP coated aluminum sheet. The film-forming material on the surface of the aluminum sheet is mainly high-weather-resistant polyester resin HDP, which has better weather resistance than ordinary polyester (PE) coated aluminum sheet.

The polyester resin used in the coating of our company's high-performance polyester HDPE coated aluminum sheet is mainly HDP resin, which does not contain aromatic intermediates and absorbs less than 10% of ultraviolet light, reducing the damage of ultraviolet light to the coating and improving the weather resistance of the coating.

Polyester coated aluminum sheet is a coated aluminum sheet made of polyester paint through a single-layer or multi-layer roller coating process. It is low-priced and can meet a variety of architectural decoration needs.

Aluminum-plastic composite panels are made of color-coated aluminum panels and low-density polyethylene through polymer materials. They are mainly used for indoor and outdoor decoration and renovation. Outdoor panels mainly use super weather-resistant fluorocarbon resin (PVDF or FEVE) coatings, while indoor decorative aluminum-plastic panels use polyester resin coatings.

Color coated aluminum sheets can be directly used for indoor ceilings in the form of squares, strips, channels, grilles, etc. Aluminum alloy materials for ceilings are mostly made with polyester roller coating 。

The creativity of aluminum cone core composite panels comes from the architectural mechanics and aesthetics of ancient Chinese arch bridges. Through horizontal pushing force, the bending moment stress originally generated by the load is transformed into compressive stress or a large part is converted into compressive stress, greatly reducing the bending moment of the arch. The arch mainly bears compressive force, fully utilizing the compressive strength of aluminum composite materials. Color coated aluminum plates play an extremely important role in the development of aluminum cone core plates, with excellent aluminum alloy performance, colorful color choices, A-level anti glare performance, environmental protection, and zero formaldehyde coating performance, greatly promoting the development of aluminum cone core plates.

Corrugated composite aluminum plate is a new type of building decoration material, which is made by pressing aluminum plate into corrugated core material and then bonding it with color coated aluminum plate on one or both sides with high strength composite production. It is mainly used for ceiling decoration. The process can use hook and loop board or buckle board, which has the advantages of light weight, high strength, good flatness, rich appearance, and convenient installation and construction. At the same time, it also has the characteristics of earthquake resistance, fire resistance, fire resistance, service life, and maintenance free

Nowadays, many aluminum-plastic panels (ACP） are used as advertising boards. The required patterns, fonts, or a combination of patterns and fonts of various colors are directly printed on the aluminum-plastic panel using UV ink.It is used for advertising media publicity, urban beautification, signboards, warning signs, etc. This requires that the surface of the color coated aluminum plate and the UV ink have excellent adhesion, The panel surface is bright and flat, with good weather resistance and strength.

Color coated aluminum plates are increasingly being used in the field of home appliances and electronic products. Some are made of color coated aluminum plates to form heat-resistant aluminum-plastic panels and then applied to home appliances and electronic products, such as TV backboards, while others are directly used in home appliances and electronic products, such as refrigerator panels and side panels, phone back cases, laptop panels, etc.
